Race Trailers


Internal "full height" gooseneck semi-trailer, with Dhollandia racing tailgate.



High load volume capacity suitable for stowing materials with different dimensions. Not being equipped with under chassis lockers, it has a total internal height of 3400 mm which is used to the maximum and divided into two loading floors. The height of the first loading floor is approx. 1895 mm. The height of the second loading floor is approx. 1420 mm. The internal shape of the first floor covers the axle area. Possibility of loading 3 vehicles on the second floor and 1 / 2 vehicles on the first floor. The second loading floor is usually built with a fixed reinforced floor, but on request it can also be fitted with a manually adjustable mechanism or with remote controlled hydraulic system.
Options: living, sliders, pop up.


Contact us for your project Download datasheet

Racing team solutions


Great internal height



The Z3 model is the ideal solution for the professional racing team: great performance and racing attitude.







Customizable

with the addition of the slider



Z3 TECHNICAL SPECIFICATIONS
Brand Astacar
Model Z3
Color WHITE RAL 9003
Total weight 28.000 KG
Axles 2
Tires 265/70 R19,5
Length 13.955 mm
Width 2540 mm
Height 4000 mm

Inside height 3365 mm
Lift DHOLLANDIA 2500 – 3000 KG
Lift entry 2200 mm
King pin height 1110 mm
Lateral door 1 ON THE RIGHT SIDE
Loading capacity : 5 CARS MAXIMUM
Gooseneck YES
Underfloor lockers NO
Windows 2
